Nishra Overseas LLP is the leading Importer, Supplier, and Exporter of Aluminium Flanges for its valued customers. We guarantee that superior quality alloy is used to create these flanges. To satisfy the needs of our esteemed customers, we maintain a large inventory of these aluminum flanges. To guarantee the quality of our products, we use cutting-edge machinery and technology when making these flanges. These flanges come in a variety of sizes, forms, classes, standards, dimensions, grades, and other specifications, and we manufacture them to the client's specifications.

Aluminum Industrial Flanges, Aluminum Alloy Pipe Flanges Trader, Aluminum Reducing Flanges, Nickel Alloy SWRF Flanges, Competitive Price of Aluminum Alloy Slip on Flange, Ready Stock of ASME SB247 Aluminium Alloy Flanges, Largest Stockholder of Aluminum Alloy Flanges in India, Alloy Weld Neck Flanges, ASTM B247 Socket weld Flanges Manufacturers in Mumbai, India.

Aluminum alloys include high amounts of aluminum. Additionally, this alloy comprises manganese, silicon, tin, copper, zinc, and magnesium. Aluminum alloy's remarkable properties make it the most demanding alloy in industrial applications. Because of its superior properties, this alloy is used in a wide range of sectors. Aluminum alloys shield the surface from the damaging elements outside and have exceptional corrosion resistance. This metal is lightweight and has good electrical and thermal conductivity. Aluminum Alloy Flanges constructed from this alloy have good features such as formability, weldability, malleability, tensile strength, and others.

We are Leading Exporter and Supplier of ASTM B247 Aluminium Lap Joint Flange, Aluminium Class 150 Flanges Raised Face, Aluminium Reducing Flange, Aluminium Threaded Flange, MSS SP-44 Aluminium Socket Weld Flange, Aluminium Tongue and Groove Flange, Aluminium Weld Neck Flange, Aluminium Spectacle Blind Flange Flat Face, Aluminium Nipoflange, Aluminium Weldoflange, Class 300#, 600#, 900#, 1500#, 2500# Aluminium Flanges Dimensions.

Aluminum flanges are widely used in a variety of industrial applications. These flanges are used in a wide range of sectors, including paper, oil and gas, pharmaceuticals, fertilizers, food and dairy, petrochemicals, chemicals, and desalination facilities. These flanges are also used in nuclear power plants, electric power plants, water system pipe projects, and more. Following manufacture, these flanges are tested for rigorous quality inspections to ensure their long-term durability. This is accomplished using a variety of tests, including PMI, IGC, hardness, tensile, chemical, mechanical, micro, and macro.

Aluminum Flanges Specification

Specifications	ASTM B564 / ASME SB564
Size Chart of SS Blind Flanges	1/2″ (15 NB) to 48″ (1200NB)
Standards	ANSI/ASME B16.5, B 16.47 Series A & B, B16.48, BS4504, BS 10, EN-1092, DIN, etc.
Class / Pressure rating of SS WN flanges	150#, 300#, 600#, 900#, 1500#, 2500#, PN6, PN10, PN16, PN25, PN40, PN64 etc.
American Standard of SS Flanges	ANSI Flanges, ASME Flanges, BS Flanges, DIN Flanges, EN Flanges, etc.
Flange Forging Methods	Forging/ Casting/ Rolling And Cutting
Pressure Calculation in DIN	PN6, PN10, PN25, PN40, PN64 \| 6Bar, 10Bar, 16Bar, 25Bar, 40Bar.
Test Certificates	EN 10204/3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report, etc

Aluminum Flanges Dimensions Chart

NPS (in.)	Hastelloy Flange Dimensions
NPS (in.)	Dia. of Flange (in.)	No. of Bolts	Dia. of Bolts (in.)	Dia. of Bolt Holes (in.)	Bolt Circle (in.)
1/4	3-3/8	4	1/2	0.62	2-1/4
1/2	3-1/2	4	1/2	0.62	2-3/8
3/4	3-7/8	4	1/2	0.62	2-3/4
1	4-1/4	4	1/2	0.62	3-1/8
1-1/4	4-5/8	4	1/2	0.62	3-1/2
1-1/2	5	4	1/2	0.62	3-7/8
2	6	4	5/8	0.75	4-3/4
2-1/2	7	4	5/8	0.75	5-1/2
3	7-1/2	4	5/8	0.75	6
3-1/2	8-1/2	8	5/8	0.75	7
4	9	8	5/8	0.75	7-1/2
5	10	8	3/4	0.88	8-1/2
6	11	8	3/4	0.88	9-1/2
8	13-1/2	8	3/4	0.88	11-3/4
10	16	12	7/8	1	14-1/4
12	19	12	7/8	1	17
14	21	12	1	1.12	18-3/4
16	23-1/2	16	1	1.12	21-1/4
18	25	16	1-1/8	1.25	22-3/4
20	27-1/2	20	1-1/8	1.25	25
24	32	20	1-1/4	1.38	29-1/2

Aluminum Flanges Weight Chart

Pipe Normal Diam.		O.D. Flange	Thk. Of Flange Min	Diam. of Hub	Diameter of Raised Face	Length Hub.Y	Thread Length	Diam. of Bolt Circle	Diam. of Bolt Holes	Number of Bolts	Diam. of Bolts (inch)	KG	LB
inch	dn	O	C	X	G	Y	T	BC	BH	BN	BD
1/2″	15	89.00	11.20	30.20	35.10	15.70	15.70	60.50	15.80	4	1/2″	0.4	0.9
3/4″	20	98.50	12.70	38.10	42.90	15.70	15.70	69.90	15.80	4	1/2″	0.7	1.5
1″	25	108.00	14.20	49.30	50.80	17.50	17.50	79.30	15.80	4	1/2″	0.8	1.8
1-1/4″	32	117.50	15.70	58.70	63.50	20.60	20.60	88.90	15.80	4	1/2″	1.2	2.6
1-1/2″	40	127.00	17.50	65.00	73.20	22.40	22.40	98.60	15.80	4	1/2″	1.5	3.3
2″	50	152.50	19.10	77.70	91.90	25.40	25.40	120.70	19.10	4	5/8″	2.3	5.1
2-1/2″	65	178.00	22.40	90.40	104.60	28.40	28.40	139.70	19.10	4	5/8″	3.7	8.1
3″	80	190.50	23.90	108.00	127.00	30.20	30.20	152.40	19.10	4	5/8″	4.1	9
3-1/2″	90	216.00	23.90	122.20	139.70	31.80	31.80	177.80	19.10	8	5/8″	5.1	11.2
4″	100	228.50	23.90	134.90	157.20	33.30	33.30	190.50	19.10	8	5/8″	5.9	13
5″	125	254.00	23.90	163.60	185.70	36.60	36.60	215.90	22.40	8	3/4″	7	15.4
6″	150	279.50	25.40	192.00	215.90	39.60	39.60	241.30	22.40	8	3/4″	8.4	18.5
8″	200	343.00	28.40	246.10	269.70	44.50	44.50	298.50	22.40	8	3/4″	13	28.6
10″	250	406.50	30.20	304.80	323.90	49.30	49.30	362.00	25.40	12	7/8″	18	39.5
12″	300	482.50	31.80	365.30	381.00	55.60	55.60	431.80	25.40	12	7/8″	29	64
14″	350	533.50	35.10	400.10	412.80	57.20	57.20	476.30	28.50	12	1″	39	86
16″	400	597.00	36.60	457.20	469.90	63.50	63.50	539.80	28.50	16	1″	47	103
18″	450	635.00	39.60	505.00	533.40	68.30	68.30	577.90	31.80	16	1 1/8″	57	126
20″	500	698.50	42.90	558.80	584.20	73.20	73.20	635.00	31.80	20	1 1/8″	76	167
24″	600	813.00	47.80	663.40	692.20	82.60	82.60	749.30	35.10	20	1 1/4″	97	214

Aluminum Flanges Pressure Ratings

ANSI/ASME B16.34	PRESSURE RATING CHART
Temperature °F	150#	300#	400#	600#	900#	1500#	2500#
-20 to 100	275	720	960	1440	2160	3600	6000
200	230	600	800	1200	1800	3000	5000
300	205	540	720	1080	1620	2700	4500
400	190	495	660	995	1490	2485	4140
500	170	465	620	930	1395	2330	3880
600	140	435	580	875	1310	2185	3640
650	125	430	575	860	1290	2150	3580
700	110	425	565	850	1275	2125	3540
750	95	415	555	830	1245	2075	3460
800	80	405	540	805	1210	2015	3360
850	65	395	530	790	1190	1980	3300
900	50	390	520	780	1165	1945	3240
950	35	380	510	765	1145	1910	3180
1000	20	320	430	640	965	1605	2675
1050	20	310	410	615	925	1545	2570
1100	20	255	345	515	770	1285	2145
1150	20	200	265	400	595	995	1655
1200	20	155	205	310	465	770	1285
1250	20	115	150	225	340	565	945
1300	20	85	115	170	255	430	715
1350	20	60	80	125	185	310	515
1400	20	50	65	95	145	240	400
1450	15	35	45	70	105	170	285
1500	10	25	35	55	80	135	230

Ready Stock of Aluminum Flanges

Aluminium Weld Neck Flange	Aluminium Expander Flanges
Aluminium Long Weld Neck Flange	Aluminium Reducing Flanges
Aluminium Slip On Flange	Aluminium Male & Female Flanges
Aluminium Spectacle Blind Flanges	Aluminium Weldolet Flange
Aluminium Socket Weld Flanges	Aluminium Nipolet Flange
Aluminium Blind Flange	Aluminium Backing Ring Flanges
Aluminium Threaded Flanges	Aluminium Ring Spacer Flanges
Aluminium Orifice Flanges	Aluminium Paddle Blind Flanges
Aluminium Lap Joint Flanges	Aluminium Plate Flange
Aluminium Square Flanges	Aluminium High Hub Blind Flange
Aluminium Ring Type Joint Flanges	Aluminium Custom Flanges
Aluminium Tongue and Groove Flange	Aluminium Swivel Ring Flange

Aluminium Flanges Applications

Oil and Gas Processing	Dairy and Food Processing
Desalination	Pesticides
Pulp and Paper	Sugar Factory
Energy industries	Power Plants
Ship Building	Fertilizers
Machine Building	Nuclear
Pharmaceuticals	Chemicals
Textile Machinery	Synthetic Fibers
Construction	Modern Architecture
Refinery & Petrochemicals	Water treatment facilities

Aluminium Flanges Marking

Every Standards have clearly requirements for steel flanges’ marking style, usually the marking words include seller’s Logo, buyer’s Logo (OEM), standard number, flange’s type, flange’s pressure, flange’s size, flange’s material, place of origin, heat number and other words for convenient to trace. If the flanges repaired by welding, it must mark on flanges showing this flange repared by welding. If the flange’s dimensions (OD, ID, PCD, Thickness, Holes number, Holes diameter, Tolerance etc) are different with the normal standard, it also must mark on flanges where it is different with normal ones. Another important place is heat number marking, it is the tracing base for every piece flange, and from the heat number we can trace to the beginning of raw material import.

The Marking Style for European Standards Flanges, DIN, UNI, EN 1092-1 norms etc
LOGO, EN 1092-1, TYPE 01, PN16, DN80, 88.9, P265GH, HEAT NUMBER
The Marking Style for ANSI, ASME Standards Flanges, ANSI, ASME, AWWA norms etc LOGO, ASME B16.5, CLASS 150#, SLIP-ON RF, A105, HEAT NUMBER
The Marking Style For JIS, KS norms etc, special with KS Mark
LOGO, JIS B2220, 5K, 80A, SOP, SF440A, HEAT NUMBER, KS MARK
The Marking Style for BS 4504 norms etc
LOGO, BS 4504, WELD NECK, PN40, DN80, RSt37.2, HEAT NUMBER
The Marking Style for GOST 12820, GOST 12821 norms etc
LOGO, GOST 12820, PN1.6MPA, DN80, Q235B, HEAT NUMBER
The Marking Style for SABS 1123, SANS 1123 norms etc
LOGO, SABS 1123, CLASS 4000/3, NB80, A105, HEAT NUMBER

Aluminium Flanges for Shipping, Handling, and Packaging

Carbon Steel, Alloy Steel Flanges and Stainless Steel Slip On Flanges are delivered with or without surface protection, as determined by the manufacturer.

The company delivers Aluminium Flanges in standard packaging, without surface protection or end protectors (caps). Special packaging, protective covers, and end protectors (caps) can be agreed upon.
